Polycrystalline photovoltaic modules 90 Wp

• Efciency 17 %
• Positive tolerance 0/+3 %
• Certifcates – TUV, CE, EN 61215, EN 61730

Electrical data

• Number of cells; 18
• Peak power: 90 Wp
• Voltage at maximum power: 19,4 V
• Open circuit voltage: 22,9 V
• Current at maximum:  4,65 A
• Short-circuit voltage:  4,95 A
• Working temperature, from -40 to 85 °C
• Nominal operating cells temperature:  45°C
• Maximal system voltag :  1000 V

Technical data

• Module dimensions: 788 x 670 x 40 mm
• Junction box IP-65, 3 diode, cables 2х1 m, connectors MC4
• Tempered low-iron solar glass 3,2 mm
• Frame Anodized aluminium
• Weight: 8 kg
